DLK1-10A DLK1-10AT/16A/25A40A Tianjin Wenda electromagnetic clutch Machine tool milling machine accessories Item NO.: 1943307

DLK1 dry multi plate electromagnetic clutch

1、 Main purpose

DLK1 series fast electromagnetic clutch is a kind of magnetic flux plate, with sensitive and reliable action. It is easy to adjust after the friction plate is worn, and the no-load torque is small. It is mainly used in mechanical transmission systems such as handling, steel rolling, semi-automatic lathe, CNC lathe and textile to realize functions such as clutch, reversing, speed change, braking and positioning.

2、 Model meaning

3、 Working conditions

1. The altitude shall not exceed 2000m;

2. Ambient air temperature is - 5 ℃ ~ + 40 ℃;

3. The surrounding medium has no explosion hazard and no conductive dust of gas sufficient to corrode metal and damage insulation;

4. The power supply voltage fluctuation of clutch and brake coil shall not exceed + 5% and - 15% of the rated voltage;

5. The friction plate shall be clean and free of oil stain.

4、 Installation

1. Check that the friction plate is free of oil and sundries before installation;

2. It shall be fixed axially during installation. If the split shaft is installed, the coaxiality shall be maintained at level 9;

3. After the friction plate is worn, adjust the air gap δ。

The method is: loosen the screw on the adjusting nut, turn the adjusting nut, and make the δ Reach the values specified in the table before tightening the screws.

5、 Main performance parameters

Main Technical Data

Specifications

Rated dynamic moment N.m

No load torque

(≦) N.m

On time

(≦)S

Off time

(≦)S

Rated voltage

D.C.V

Coil power consumption (20 ℃) w

Maximum allowable speed r / min

weight

Kg

two point five

twenty-five

zero point one zero

zero point one zero

zero point zero three

twenty-four

sixteen point five

three thousand and five hundred

two

five

fifty

zero point two zero

zero point one four

zero point zero four

twenty-four

twenty point five

three thousand

three

ten

one hundred

zero point three zero

zero point one six

zero point zero six

twenty-four

twenty-eight point eight

three thousand

four point five

sixteen

one hundred and sixty

zero point eight zero

zero point two zero

zero point two zero

twenty-four

forty-eight

two thousand and five hundred

five point nine

twenty-five

two hundred and fifty

one point two zero

zero point two seven

zero point two seven

twenty-four

fifty-three

two thousand and two hundred

eight point nine five

forty

four hundred

two

zero point three five

zero point three five

twenty-four

sixty-two

two thousand

thirteen point four five

eighty

eight hundred

four

—

—

twenty-four

seventy-nine

—

—
