Wheat rice suction specific gravity stone remover Peanut, soybean and corn cleaner Vibration layered screening machine Item NO.: 1944580

Suction specific gravity stone remover is mainly used in grain processing plants. It can also be used to separate impurities in other grains. The machine uses the physical properties of grain and shoulder stone with different specific gravity and suspension speed, and promotes the classification of grain and shoulder stone by means of the air flow upward through the grain particle gap. The shoulder stone and other heavy impurities are mixed in the lower layer, move to the stone outlet end under the action of the stone removal screen plate with directional inclined reciprocating motion, and the grain floating in the upper layer flows to the material outlet end under the action of self weight, So as to separate the stone from the grain.

Production capacity: 1500 kg / h

Voltage: 380V

Motor power: 0.75kw

Applicable objects: corn, soybean, bean, sesame, rice, millet, peanut, etc

Inclination of stone removal sieve plate: 10-14 degrees

Sieve plate size: 1160 * 500mm

Suction air volume: 3000 m3 / h

Overall dimension: 1360 * 600 * 1300

Weight: 200kg
