Electromagnetic clutch DLM3-1.2A DLM3-2.5A DLM3-5A 10A Wet multi disc electromagnetic clutch Item NO.: 1945325

Dlm3 series clutch is a wet multi disc electromagnetic clutch without slip ring, which needs to work under the condition of lubrication, with small friction plate wear and long service life. With small radial size and large torque, it can be widely used in the mechanical transmission system of machine tools, steel rolling, metallurgy and mining, metal calendering, transportation, ship fishing and other equipment, playing the role of clutch, reversing, speed change, etc.

The clutch can work reliably under the following conditions:

1. The ambient air temperature is - 5 ℃ - + 40 ℃.

2. In the medium without explosion risk, and there is no gas and conductive dust in the medium that can corrode metal and destroy insulation.

3. The clutch should work under the condition of lubricating oil.

4. The voltage fluctuation of clutch coil shall not exceed + 5% and - 15% of rated voltage.

5. The altitude of clutch installation site shall not exceed 2000 meters.
