BDR explosion-proof electric heating oil heater CBDR BYT explosion-proof electric heating oil heater 2000w Item NO.: 1950526

Please contact customer service

7 pieces of explosion-proof hot oil tin are explosion-proof electrical equipment for explosive environment, which can be used in places where the concentration of combustible mixture belongs to IIC T4 group and below. This product is composed of explosion-proof electric heating tube, explosion-proof temperature controller, explosion-proof signal lamp and heat sink. Using CD heat conduction oil as medium, diffusing heat through heat sink to achieve hot air circulation and improve room temperature.
Features of 7 pieces of explosion-proof electric heating oil tin
1. The product is oil-heated equipment, which is used for heating in winter or increasing the temperature of low temperature environment;
2. The temperature can be adjusted as required
3. Mobile equipment
4. Cable wiring.
5, the biggest characteristic of the heater is that the heat emitted is large, even in the case of a sudden power failure, it will maintain a certain temperature for a long time, at the same time, it does not produce any harmful gas, no electrical noise. The surface temperature of electric heating oil tin heater is lower, generally not more than 85℃, even if touching the human body will not cause burns, suitable for the human body may directly touch the place for heating.
7 pieces of explosion-proof electric heating oil tin applicable scope
Hazardous gas sites in zone 1, 1 and 2
2, A and B Ⅱ Ⅱ T1 ~ T4 group explosive gas or steam environment.
3. This product is used as explosion-proof electrical equipment in explosive environment, and can be used in places where the concentration of combustible mixture belongs to group T4 of IIC level or below.
Technical parameters of 7 pieces of explosion-proof electric heating oil tin
Rated voltage (V) : 220V/50HZ
Power (W) : 1500
Specification (sheet) : 7
Explosion-proof marks: Exd Ⅱ BT4
Overall dimension: 485X150X640
Inlet thread (G ") : 3/4
Cable outside diameter (mm) : 10-14
