Time relay DS-34 DS-32 DS-34/2 relay DS-31 31C 32C 32X 33 33X Item NO.: 1950354

Write a Review

US$ 35.00

Quantity: Stock ( 20 )

Estimate Shipping Cost

Time relay DS-34 DS-32 DS-34/2 relay DS-31 31C 32C 32X 33 33X

Product Name	Time relay DS-34 DS-32 DS-34/2 relay DS-31 31C 32C 32X 33 33X
Item NO.	1950354
Weight	3 kg = 6.6139 lb = 105.8219 oz
Category	Explosion-proof electrical apparatus
Creation Time	2022-05-02

Main technical data

Product model

Rated voltage

Delay setting range

Action time variation

Power consumption

DS-111C

24V、48V

110V、220V

0.1-1.3s

0.06s

DS-112C

0.25-3.5s

0.12s

DS-113C

0.5-9s

0.25s

DS-111

0.1-1.3s

0.06s

DS-112、115

0.25-3.5s

0.12s

DS-113、116

0.5-9s

0.25s

DS-121

110V、127V

220V、380V

0.1-1.3s

0.06s

DS-122、125

0.25-3.5s

0.12s

DS-123、126

0.5-9s

0.25s

● Action value: DC relay shall not be greater than 70% of rated value; AC relay shall not be greater than 85% of rated value.

● Return value: not less than 5% of rated value.

● Contact capacity: in the DC inductive load circuit with voltage not exceeding 250V, current not exceeding 5A and time constant of 5 ± 0.75ms, the breaking capacity of the product output contact is 50W. Under the above specified load conditions, the output contact can reliably act and return 5 × 104 times. The long-term allowable making current of the output contact is 5A.

● Dielectric strength: the conductive terminals of the product are connected together. The exposed non live metal parts or shells can withstand an AC voltage of 2000V (effective value) 50Hz for 1 minute without insulation breakdown or flashover.
