Reclaim the complete set of cutting machinery for waste tires in the factory Crown separation equipment Mouth ring slitting crus Item NO.: 1945494

Usage of ring cutting machine: cut and separate the sidewall and crown of waste tires for the next step of segmentation. It is the first process to deal with waste tires;

Application of slitting machine: it is used to cut the steel wire tire from the tire opening of the ring cutting machine into strips. It is mainly used to cut the crown and sidewall of waste tires into rubber strips with a certain width, and the width of the strips can be adjusted;

Application of the slicer: it is used to cut the long tire strips cut by the slicer into blocks;

Usage: the machine is mainly used to separate the rubber on the steel ring of various tires from the steel ring, so as to obtain a complete steel ring

Ring cutting machine

Production efficiency: 60 / h

Motor power: 3kw

Motor speed: 1440r / min

Voltage: 380V

Frequency: 50Hz

Equipment weight: 300kg

Applicable tire size: 650-1200mm

Overall dimension: 1300 * 900 * 1200mm

Slitter

Overall dimension: 1250 × seven hundred × 1500mm

Production efficiency: 1000-1800kg / h

Motor power: 5.5kw

Motor speed: 1440 R / min

Voltage: 380 V, frequency: 50 Hz

Reducer model: 350, reduction ratio: 31.5

Discharge size: 20-40mm

Equipment weight: 670kg

Overall dimension: 1300 * 700 * 1500mm

Cutting machine

Overall size: 850 × eight hundred and fifty × 1200mm

Production efficiency: 1000-1800kg / h

Motor power: 11kw

Motor speed: 1440 R / min

Voltage: 380 V, frequency 50Hz

Discharge size: 20-50mm

Equipment weight: 620kg

Mouth ring separator

Overall dimension: 1500 × nine hundred × 1400mm

Production efficiency: 120 / h

Motor power: 15kw

Motor speed: 1440 R / min

Voltage: 380V, frequency: 50Hz

Reducer model: 400

Reduction ratio: 40.17

Equipment weight: 1300kg
