Explosion-proof heater Waterproof and explosion-proof heater Field oil field task Wall mounted Item NO.: 1944667

Please contact customer service

Temperature-controlled heater is characterized by the integration of temperature controller and heating plate, which makes the product more safe and reliable and easy to install. This product can be used as a fully automatic temperature control heater for field work vehicles, movable panel rooms, laboratories, offices and other places. When the greenhouse reaches the temperature you set, it closes automatically, and when the temperature is lower, it opens automatically.
The temperature control heater is introduced in detail.
First, characteristics and uses
Our company's latest development of a new generation of temperature-controlled heater, which is characterized by the integration of temperature controller and heating plate, so that the product is more secure and reliable, but also easy to install. This product can be used as a fully automatic temperature control heater for field work vehicles, movable panel rooms, laboratories, offices and other places. When the greenhouse reaches the temperature you set, it closes automatically, and when the temperature is lower, it opens automatically.
Two, structure
This product is composed of metal tubular electrothermal elements, galvanized mesh, stainless steel cover, temperature controller and other major components. Normal service life of more than five years, and no special requirements such as maintenance and repair.
Three, performance
This product uses metal tube electric heating element as heating body. There are several small holes on the galvanized cover, which are not limited by the fluctuation of power supply voltage. It has no noise, smoke and dust, uniform temperature, no drying heat sense, high mechanical strength, simple installation and beautiful appearance.
IV. Technical Indicators
1. Temperature control range: 0 C - 35 C. When the room temperature is below 0 C, the switch can not be turned off.
2, enclosed heating space up to standard; 15M3/KW
3. Heat equivalent: 860 calories per kilowatt hour.
4. Cold insulation resistance: > 10M
5. Maximum control current: 15A
6. Power frequency withstand voltage: 2KV/1min
7. Continuous working hours: > 5000 hours
Five, specifications
1. Shape size: 600mm * 300mm * 95mm rated voltage: 220V heating power: 1500W 2000W
2. Shape size: 600mm * 380mm * 115mm rated voltage: 220V heating power: 3000W (can also be customized according to customer requirements).
6. Installation and use
1. According to the size of indoor space and the position of indoor objects, the heater is installed in the appropriate position. Generally, two 1500W heaters or one 3000W heater can be used in a room without exceeding 35m3.
2. Remove the screw at the four corners of the heater is the installation hole. Fix the screw on the base first according to the matching installation, and then fix the installation frame to the installation position. In order to prevent the wall carbonization caused by long-term use, the heater should keep a distance of more than 7 centimeters from any wall during installation, and the installation height should be higher than 7 centimeters. No more than 1.8 meters
Seventh, matters needing attention
1. It is strictly forbidden to place the heater directly under the power outlet.
2. It is strictly forbidden to put the heater under the partition board.
3. It is strictly forbidden to place explosive, flammable and damp objects on heaters in order to avoid accidents.
8. Daily maintenance
If the heater does not heat, the indicator lights are not on and the line is not connected, please contact the manufacturer. Our company sends professional personnel to repair the heater. The user is not a professional person and can not repair it by himself.
2. If the wires are damaged, they must be replaced by professionals. We can also contact our company.
Ninth, after-sales service
1. Our company will provide all technical services and consultation whenever we use our products.
2. Users have special specifications and technical requirements for our products. Our company will wholeheartedly meet them.
Note: Use this product must be reliable grounding!
Warning: To avoid overheating, do not cover the heater!
