Explosion-proof flat desk lamp Explosion-proof fluorescent lamp 20W 40W 60W led BYD702 Long strip explosion-proof lamp Item NO.: 335051





Used in hazardous gas environment zone 1 and zone 2

Used in zone 20, zone 21 and zone 22 of explosion-proof dust environment

Suitable for IIA IIB IIC explosion-proof gas environment

Suitable for temperature group t1-t6 environment

Floodlight is used for oil mining, refining, storage, chemical industry, textile, printing and military installations, dangerous places



Byd702-led20w byd702-led30w byd702-led40w byd702-led50w byd702-led60w

Ordering instructions:

Lamps and lanterns factory has been equipped with good light source access to power can be used

Please select accessories according to the meaning of the model

For example, if you order BYD702 series maintension-free low carbon LED lighting, the light source is LED60 watt, the installation mode is top suction type, and the junction box is equipped.

When ordering: byd702-led60wx



Appearance features: round and full shape, strong and powerful reinforcement, rigid oblique cut surface, circular cloth art groove, nameplate and shell ring of the special color, forming the unique PI element of the well

Product advantages and features

The shell is die-cast aluminum alloy, after shot blasting, high voltage electrostatic spraying

The lamp adopts the explosion-proof structure of thread and link, which has excellent explosion-proof performance

Exposed fasteners are made of stainless steel with high corrosion resistance

Lamps and lanterns shall be wired with steel pipe or cable and shall be installed in a variety of ways

Technical parameters:

Explosion-proof mark: ExdIICT6GB/DIP a20.t6

Working voltage: AC110V-AC264V 50/60hz

Rated power: 20W 40W 60W

Assembly light source: LED

Luminous efficiency: 110 lm/w

Power factor: 0.95

Color rendering index: Ra>75 c 1 c 3

Inlet specification: g3/4

Outer diameter of cable: 9mm-14mm
