Crawler type woodworking lath edge cleaning saw multi blade saw Full automatic infrared edging saw Wood board sawing machine Item NO.: 1944573

The main function of the multi blade saw is to square and slice the sheet, or all the sheets. It is suitable for dry and wet material processing. It is an equipment for processing and forming all kinds of plates. It can be used for softer miscellaneous wood such as Chinese fir, pine, pressed wood and poplar. It refers to common equipment such as finger joint board, joinery board, cabinet board, bed board, building furniture, wooden square and so on.

1. Zui large sawing thickness: 30mm

2. Sawing width specification: 5-550mm

3. Zui short sawing length: 25mm

4. Saw blade specification: φ 160mm

5. Circular saw tooth thickness: 1.8mm

6. Saw shaft speed: 3000rpm

7. Main motor power: 5.5kw

8. Automatic conveying speed: 1-18m / min

9. Overall size: 1200 * 800 * 1100mm

10. Weight: 350 kg
