Automatic feeding and returning wood bar cutting machine Wood processing round bar machine Rolling pin stair handrail sawing mac Item NO.: 1945437

The round stick machine is a round stick machine for wood processing. It adopts two functions of automatic feeding and automatic return. It can be used to process and make round sticks such as wooden uneven bars, martial arts sticks and other sports equipment, rolling pins, Mine pillars, stair handrails and so on. It can adjust the cutting amount on both sides and process multi heel sticks at one time.

Zui small machining length: 250mm

Zui large machining length: 6000mm

Zui small machining width: 10mm

Zui large processing width: 120mm

Zui small machining thickness: 6mm

Zui large processing thickness: 100mm

Feeding motor power: 1.1kw

Feeding speed: 4-20m / min

Motor power of the first lower cutter shaft: 5.5kw

Second upper cutter shaft motor power: 5.5kw

Lifting motor power: 0.37kw

Cutter shaft speed: 8500 / min

Zui large cutter diameter: 120mm

Dust suction port size: 120mm

Spindle diameter: 30mm

Total power: 12.47kw

Overall dimension: 1435 * 760 * 1355mm
